Description

Algiz RT7 Full Specifications

RT7

Size – 216 mm x 128 mm x 24 mm (8.5” x 5” x 0.9”)
Weight  – 650 grams (22.9 oz) (including battery)
Processor – Qualcomm® MSM8916 – quad core ARMCortex A53, 1.2 GHz
Memory/Disk 2 GB LP-DDR2, 32-bit @ 200 MHz DDR 533 MHz. Storage: 16 GB eMMC1

Operating System Android 6.0 (Marshmallow) Google GMS (Google Play)

Screen 7″ WSVGA (1024×600); 600 nits, capacitive 5-point multi-touch, chemically strengthened glass Keypad 4 programmable function keys
Battery Li-Ion, 3.7V 6000 mAh (22.2Wh)
Connections USB A Host, USB micro (PC sync and charging), RJ45 (Ethernet), 3.5 mm headset (stereo and mic), 3.5 mm DC inlet I/O slot Dual SIM slots (user accessible), SDHC slot 32 GB
Communication – Audio: Built in: Microphone, 1.8W speaker. PAN: BT Class 1 & 2, V4.1. Cellular (WWAN): Voice and data, 2.5G (GSM, GPRS,EDGE) 3G (UMTS, HSPA+) 4G (LTE)
Wireless LAN: 802.11 b/g/n, 2.4 GHz. NFC: NFCIP-1 and NFCIP-2, ISO/IEC14443, ISO/IEC 15693, ISO/IEC 18000-3, MIFARE and FeliCa
Navigation Integrated with stand-alone u-blox® GPS (EVA-7M, position accuracy with SBAS 2m CEP)/Built-in GPS Qualcomm® IZat
Camera 8-megapixel rear-facing camera with autofocus and LED illumination 2-megapixel front-facing camera
Indicators LEDs: white, green, red, yellow and blue indicators Vibration motor
Sensors 3-axis accelerometers – 3-axis gyroscope, eCompass,

Environment
Operating: – 20 °C to 50 °C (-4 °F to 122 °F) MIL-STD-810G, Method 501.5/502.5 Procedure II,III
Storage: -40 °C to 70 °C (-40 °F to 158 °F) MIL-STD-810G, Method 501.5/502.5 Procedure I
Drop: 26 drops from 1.22 m (4 ft) MIL-STD-810G, Method 516.6 Procedure IV
Vibration: MIL-STD-810G, Method 514.6 Procedure I
Sand & Dust: IP65, IEC 60529
Water: IP65, IEC 60529
Humidity: MIL-STD-810G Method 507.5 Procedure II
Altitude: 4572 m / 15.000 ft MIL-STD-810G, Method 500.5 Procedure I

Included in box: RT7 International power adapter, Battery, 3.5 mm headset, USB cable, Quick-start guide.
